H type chicken layer cage for poultry farm
In a house of 100m*13m, if 4 tier cages are installed, 39 units of cage per line, the height of side wall should be 4m, and total birds quantity is 37400;
if 5 tier cages are installed, 39 units of cage per line, the height of side wall should be 4.5m, and total birds quantity is 46800;
if 6 tier cages are installed, 39 units of cage per line, the height of side wall should be 5.0m, and total birds quantity is 56160.
Surface treatment:Electro galvanize(1.Surface smooth, and bright, zinc coating: 20-30g/m2,2. In the humid environment, it is easy to rust, But after the rust does not affect use, service life:8-10 years). Because the cost is low, after rust does not affect the use.
So most people in use hot galvanize (1. surface zinc is thick, can reach about 500g/m2,It has the corrosion resistance of high strength. 2. the surface have zinc knot, not smooth, service life: 25 years--Even for a longer time)
Pvc powder after electric galvanized( 1.Surface smooth,and bright,Color can choose:Red, yellow, blue, green, black, white.2.Because this is two layers of surface treatment, antirust ability enhancement,It is not easy to rust, service life:20 years)
1.Reduce feed wastage and maximize productivity in layer production
2.Increased production
3.Better overall management of flock
4.Save on labour costs
5.Zero accidental mortalities
6.More effective management of poultry waste
7.The cages are reusable
| Mode | Tier/set | Nest/single cage | Nest/Complete cage | Nest size | Capacity/set | Complete cage Size: L*W*H |
| A012 | 3tier | 4nest | 24nest | 47*35cm | 96birds | 1.88*1.9*1.6M |
| A013 | 3tier | 4nest | 24nest | 50*40cm | 96birds | 2*2.1*1.6M |
| A014 | 3tier | 5nest | 30nest | 43*40cm | 120birds | 2.15*2.1*1.6m |
| A015 | 4tier | 4nest | 32nest | 50*40cm | 128birds | 2*2.3*1.9M |
| A016 | 4tier | 5nest | 40nest | 43*40cm | 160birds | 2.15*2.3*1.9M |
| A017 | 5tier | 4nest | 40nest | 50*40cm | 160birds | 2*2.5*2.4M |
| A018 | 5tier | 5nest | 50nest | 43*40cm | 200birds | 2.15*2.5*2.4M |
| A019 | 3tier | 5nest | 30nest | 39*35cm | 120birds | 1.95*1.9*1.6M |
| A020 | 4tier | 5nest | 40nest | 39*35cm | 160birds | 1.95*2*1.9M |
| A021 | 5tier | 5nest | 50nest | 39*35cm | 200birds | 1.95*2.3*2.4M |
